Power Integrations introduces the InnoSwitch3-PD family of flyback switcher ICs with built-in USB PD controller

INTEGRATED CIRCUITS Power Integrations introduces the InnoSwitch3-PD family of flyback switcher ICs with built-in USB PD controller

28.09.2021Editor: Nicole Kareta

Power Integrations, a specialist in high-voltage integrated circuits for energy-efficient power conversion, announced the InnoSwitch 3-PD family of ICs, the industry's most highly integrated solution for USB Type-C, USB Power Delivery (PD), and USB Programmable Power Supply (PPS) adapters.

Related Companies

Infineon Technologies AG

ROHM Semiconductor GmbH

PINK GmbH Thermosysteme

DEWETRON GmbH

Maschinenfabrik Reinhausen GmbH

more less

Power Integrations introduces the InnoSwitch3-PD family of flyback switcher ICs with a fully integrated solution combining USB PD, PPS, PowiGaN and FluxLink to maximize efficiency and slash component count in adapters and chargers.
(Source: ©hywards - stock.adobe.com)

This compact InSOP-24D-packaged IC includes a USB-C and PD controller, a high-voltage PowiGaN switch, a multi-mode quasi-resonant flyback controller, secondary-side sensing, FluxLink isolated digital feedback and a synchronous-rectification driver.

Aditya Kulkarni, senior product marketing engineer at Power Integrations said: “InnoSwitch3-PD ICs target designers seeking the ultimate in charger power density. This requires the highest level of integration and maximum efficiency to limit self-heating. Our latest addition to the InnoSwitch3 family dramatically simplifies the development and manufacturing of compact, energy-efficient USB PD power supplies for smartphones, tablets, notebooks, and other devices that benefit from fast charging. InnoSwitch3-PD ICs reduce the BOM count to half that of conventional designs, reducing design time and simplifying high-volume manufacture for slim, ultra-compact OEM and aftermarket chargers.”

WP-Vorschaubild_Rohde_Schwarz_WP-LG_PB_2021-07-09

Featuring no-load power consumption as low as 14 mW, power supply designs using InnoSwitch3-PD ICs meet all global energy-efficiency regulations. The high efficiency of these devices ensures low heat dissipation, eliminating the need for bulky heatsinks. Power Integrations’ FluxLink high-speed communications feedback link ensures fast, accurate secondary-side regulation. InnoSwitch3-PD ICs are also fully protected, with input voltage monitoring, accurate brown-in/brown-out and overvoltage protection, and output over- and under-voltage fault detection with independently configurable fault responses.
