FLYBACK CONVERTER SNUBBERS Verification methods of snubber circuits in flyback converters

Author / Editor: Nigel Charig / Nicole Kareta

Flyback converters are popular AC-DC solutions for electronic products consuming up to 50 W power. However, while low-cost, the basic circuits have parasitic components which cause harmful ringing and voltage spikes. This article discusses verification methods for possible snubber circuit solutions.
